Extruders - twin screws
Double-screw extruders for the production of PVC profiles and pipes
TECHNICAL DATAS:
- Suitable for PVC-U profile production
- 20D, 25D, 26D and 33D extruder screw lengths
- Output range from 80 kg/h to 800 kg/h
- High specific output for gentle plastification of PVC material
- High melt homogenity
- Touch screen control panel
- User friendly software developed by Mikrosan
- AC servo motor and drive
- High-torque gearbox
- Screw internal water thermal regulation
- Equipped with degassing zone
- Different material feeding options for stable production of PVC-U powder
- All commercial parts made in Turkey and Europe
- The profile series parallel twin screw extruders have proven and robust machine technology for stable and efficient production.
- Screws and barrels are specially designed according to the application and customer requirements.
- Screw and barrel are completely manufactured in Mikrosan including all heat treatment and nitriding process.
Extruders - twin screws - photogallery
